Model Number &
Technical Info

Product Type

General Information on Electronic Loads

EE15120A-R1
Special Order


Electronic Load
Ultra Stable
Current

 For Testing Low Power / Fuel & Solar Cells / Prim Cells

The EE15120A-R1 DC Load, Input 0.05 - 58 VDC / 20 Amps / 125W / Peak Pulse Power 150W Selectable Options, 0.05 ON-Resistance / Internal / External bias supply




EE15140A-R1
  Special Order

Electronic Load

 For Testing Low Power / Fuel & Solar Cells / Prim Cells
 also / Switches / Motors / Nicads / TPVs / Lights / Generators

The EE15140A-R1 DC Load, Input 0.05 - 58 VDC / 40 Amps / 125W / Peak Pulse Power 150W Selectable Options, 0.035 ON-Resistance / Internal / External bias supply



EE30140A-R2
In Stock!

Electronic Load
designed for
low voltages

 For Testing Medium Power / Fuel & Solar Cells / Prim Cells
 also / Switches / Motors / Nicads / TPVs / Lights / Generators

The EE30140A-R2 DC Load, Input 0.05 - 58 VDC / 40 Amps / 300W / Peak Pulse Power 400W 0.025 ON-Resistance  / Max. Slew 12 Amps/uS   Internal / External bias supply



EE30180A
In Stock!

Electronic Load
designed for
ultra low
voltages

 For Testing high Power / Fuel & Solar Cells / Prim Cells
 also for high power battery chargers & dischargers
The EE30180A DC Load, Input 0.05 - 58 VDC / 80 Amps / 300W / Peak Pulse Power 400W  0.010 ohm ON-Resistance / Max. Slew 12 Amps/uS   Internal / External bias supply



EE30181A-R1
Special Order

Electronic Load
designed for
high voltages

 For Testing high voltage / Fuel & Solar Cells / Prim Cells /
 also for high power battery chargers & dischargers
The EE30181A-R1 DC Load, Input 0.05 - 150 VDC / 80 Amps / 225W / Peak Pulse Power 400W Selectable Options, 0.035 ON-Resistance / Max. Slew 12 Amps/uS  Internal / External bias supply



EE30141A-R1
Special Order

Electronic Load
designed for
high voltages

 For Testing High Voltage / Fuel & Solar Cells / Prim Cells /
 also for high power battery chargers & dischargers
The EE30141A-R1 DC Load, Input 0.05 - 150 VDC / 40 Amps / 225W / Peak Pulse Power 400W 0.055 ON-Resistance / Max. Slew 12 Amps/uS  Internal / External bias supply



EE301-DCM
In Stock!

digital meters
for

Electronic Load

 For ee301xx / ee151xx series electronic loads
In-Line,  Current 3 1/2 digit & Voltage 3 1/2 digit LCD Meters
Internal / External bias supply





EE301-ISOL
In Stock!

isolation module
for

Electronic Load

 For ee301xx / ee151xx series electronic loads
for analog signal isolation of input and outputs / requires external
9-15 volts @ 200 ma /  good for computer done by customer





Heat-Sinks
In Stock!

heat sinks
for

Electronic Load

 For ee301xx/ee151xx & ee300xx/ee150xx series electronic loads
These heat-sinks are for High Power and / or High Temperature operation



CRIMP TOOL
Out-Side Purchase!

crimp tool
for Electronic Load connector

 For ee301xx/ee151xx & ee300xx/ee150xx series electronic loads
CRIMP TOOL - for Connector Kit's  // This tool is able to crimp BERG CONNECTOR contacts. The tool is Very Low Cost  and can also crimp old style DB-connector contacts / terminals / and many other types.

EE106T-12

CABLE POWER
for
ELECTRONIC LOAD

Cable for Qusi-Power Control Testing
12 VOLT POWER CABLE WITH LEADS USES CONTROL POTS ON ELECTRONIC LOAD FOR ADJUSTMENT.
( For Qusi-Constant Power Control using control POTS on electronic load )

EE105T-12

CABLE POWER
for
ELECTRONIC LOAD

Cable for ANALOG "D to A" & "A to D" Testing
12 VOLT POWER CABLE WITH LEADS FOR USE WITH MULTI FUNCTION CARDS or (External POT control of constant current )

AC Load

Building an AC Load from a DC
ELECTRONIC LOAD

How to build an AC Load from a DC Load
LOW COST WAY OF BUILDING AN AC-LOAD

EE106T-14
Special Order

CABLE POWER
for
ELECTRONIC LOAD

Cable for Qusi-Power Control Testing
14 - 24 VOLT POWER CABLE WITH LEADS USES CONTROL POTS ON ELECTRONIC LOAD FOR ADJUSTMENT.
( For Qusi-Constant Power Control using control POTS on electronic load )


Model Number &
Technical Info.

Product Type

General Information

FAQs ---- Questions
About Electronic Loads

Need to Know about Electronic Loads

Obsolete Products documentation only /  Obsolete Products Not In Production

  Reference Only

  Reference Only

  Reference Only

  Reference Only

Reference Only

OBS/EE15020

OBS/EE15040

OBS/EE30040

OBS/EE30080
